1550-00
Product group: 140
Inner tube: Black special heat resistant Chemigum with Oil resistant synthetic rubber
Cover: Black Wingprene, Oil resistant synthetic rubber
Temperature min. °C: -40
Temperature max. °C: +200
Media: Oil
Reinforcement: Flexten with Steel spiral
Safety factor: 1:4
Applications and characteristics: The hose is well suited as suction with pressure with pressure hose on tank cars or bulk stations. Heat resistant rubber Inner Tube.
Design: Wrapped, black with red stripe
Product code: 1550-00
| Part no. | ID mm | OD mm | Bend rad mm | Vacuum pr Max% | WP BAR | Weight kg/m |
|---|---|---|---|---|---|---|
| 15500024 | 38,10 | 56.4 | 102 | 70 | 10 | 2.19 |
| 15500032 | 50 | 64 | 200 | 90 | 40 | 1,50 |
| 15500040 | 63 | 77 | 250 | 90 | 10 | 2.4 |
| 15500048 | 75 | 90 | 300 | 90 | 1,50 | 2.95 |
| 15500064 | 101,60 | 122.4 | 254 | 70 | 10 | 5.58 |
