CEJN
Product info : Male
Product : TLX-series
Product group : 524
Type : Hydraulic
Manufacturer : Cejn
Interchangeable with : N/A
Temperature min. °C : -30
Temperature max. °C : +100
Product code: 5C10X07-6
| Part no. | Dimension | Thread | Weight kg |
|---|---|---|---|
| 5C106076101 | 3/4″ | RC 3/4″ | 1.19 |
| 5C106076301 | 3/4″ | G 3/4″ | 40,0 |
| 5C106076203 | 3/4″ | G 1″ | 1.14 |
| 5C106076231 | 3/4″ | G 3/4″ JIS ORB | 1.10 |
| 5C106076401 | 3/4″ | 3/4″ NPT | 1.19 |
| 5C106076601 | 3/4″ | 1 1/16″ – 12 UN (SAE 3/4″) | 1.18 |
| 5C107076103 | 1″ | RC 1″ | 2.67 |
| 5C107076203 | 1″ | G 1″ | 40,0 |
| 5C107076204 | 1″ | G 1 1/4″ | 1.96 |
| 5C107076233 | 1″ | G 1″ JIS ORB | 1.81 |
| 5C107076403 | 1″ | 1″ NPT | 2.07 |
| 5C107076603 | 1″ | 1 5/16″ – 12 UN (SAE 1″) | 2.59 |
| 5C108076104 | 1 1/4″ | RC 1 1/4″ | 3.63 |
| 5C108076204 | 1 1/4″ | G 1 1/4″ | 40,0 |
| 5C108076205 | 1 1/4″ | G 1 1/2″ | 40,0 |
| 5C108076234 | 1 1/4″ | G 1 1/4″ | 3.15 |
| 5C108076404 | 1 1/4″ | 1 1/4″ NPT | 3.64 |
| 5C108076604 | 1 1/4″ | 1 5/8″ – 12 UN – SAE 1 1/4″ OR | 3.61 |
