J EVGE-G
Product info : ED sealing
Product : ISO 1179-2
Product group : 790
Type : Straight
Thread type : JIC, BSP
Material : Stainless Steel 316
Product code : 7965-XX
| Part no. | Thread | Pipe dim. (mm) |
|---|---|---|
| 79650702 | G 1/8″ | 6 |
| 79650704 | G 1/4″ | 6 |
| 79650804 | G 1/4″ | 8 |
| 79650904 | G 1/4″ | 10 |
| 79650906 | G 3/8″ | 10 |
| 79650908 | G 1/2″ | 10 |
| 79651204 | G 1/4″ | 12 |
| 79651206 | G 3/8″ | 12 |
| 79651208 | G 1/2″ | 12 |
| 79651406 | G 3/8″ | 14, 15, 16 |
| 79651408 | G 1/2″ | 14, 15, 16 |
| 79651410 | G 5/8″ | 14, 15, 16 |
| 79651412 | G 3/4″ | 14, 15, 16 |
| 79651708 | G 1/2″ | 18, 20 |
| 79651712 | G 3/4″ | 18, 20 |
| 79651716 | G 1″ | 18, 20 |
| 79652112 | G 3/4″ | 25 |
| 79652116 | G 1″ | 25 |
| 79652120 | G 1 1/4″ | 25 |
| 79652616 | G 1″ | 30, 32 |
| 79652620 | G 1 1/4″ | 30, 32 |
| 79653020 | G 1 1/4″ | 38 |
| 79653024 | G 1 1/2″ | 38 |
