G M X G M
Product info : 60° cone sealing. DIN 3852, A.
Product group : 780
Type : Straight
Material : Stainless steel 316
Product code : 7802-XX
| Part no. | Thread 1 | Thread 2 |
|---|---|---|
| 78020202 | G 1/8″ M | G 1/8″ M |
| 78020204 | G 1/8″ M | G 1/4″ M |
| 78020404 | G 1/4″ M | G 1/4″ M |
| 78020406 | G 1/4″ M | G 3/8″ M |
| 78020408 | G 1/4″ M | G 1/2″ M |
| 78020606 | G 3/8″ M | G 3/8″ M |
| 78020608 | G 3/8″ M | G 1/2″ M |
| 78020612 | G 3/8″ M | G 3/4″ M |
| 78020616 | G 3/8″ M | G 1″ M |
| 78020808 | G 1/2″ M | G 1/2″ M |
| 78020812 | G 1/2″ M | G 3/4″ M |
| 78020816 | G 1/2″ M | G 1″ M |
| 78021010 | G 5/8″ M | G 5/8″ M |
| 78021212 | G 3/4″ M | G 3/4″ M |
| 78021216 | G 3/4″ M | G 1″ M |
| 78021616 | G 1″ M | G 1″ M |
| 78021620 | G 1″ M | G 1 1/4″ M |
| 78022020 | G 1 1/4″ M | G 1 1/4″ M |
| 78022024 | G 1 1/4″ M | G 1 1/2″ M |
| 78022424 | G 1 1/2″ M | G 1 1/2″ M |
| 78022432 | G 1 1/2″ M | G 2″ M |
| 78023232 | G 2″ M | G 2″ M |
